| Manufacturer: |
NDF Special Light Products B.V. |
| Lamp Power: |
2.7 Watts |
9.5 Watts |
13.0 Watts |
| Lamp Current: |
2.0 mA |
10.0 mA |
15.0 mA |
| Lamp Voltage: |
1350 Volts |
950 Volts |
880 Volts |
| Cap Type: |
Metal Tube 1.5mm dia. |
| Bulb Finish: |
Triphosphor 875 |
| Bulb Type: |
T-4.2 |
T-1½ in eighths/inch |
| Dimensions: |
135 x 77 x 5 mm |
5⅜ x 3 inches |
| Discharge Length: |
| Electrodes: |
Hollow metal tube |
| Atmosphere: |
Ar, Kr | Hg |
| Luminous Flux: |
230 lumens |
670 lumens |
840 lumens |
| Luminous Efficacy: |
87 lm/W |
70 lm/W |
64 lm/W |
| Luminous Efficacy: |
11,000 cd/m2 |
30,000 cd/m2 |
35,000 cd/m2 |
| Colour Temperature & CRI: |
CCT: 7600K |
CRI: Ra 85 |
| Chromaticity Co-ordinates: |
CCx: 0.299 |
CCy: 0.315 |
| Burning Position: |
Universal |
| Rated Lifetime: |
100,000 hours |
50,000 hours |
20,000 hours |
| Warm-up / Re-strike Time: |
1 minute |
Rated to 60% lumens |
| Factory: |
Roosendaal |
Netherlands |
| Date of Manufacture: |
2001 |
| Original / Present Value: |
|
|
